About Your System 15
.
LCD Module
The LCD module provides an initial configuration/deployment wizard, as
well as easy access to infrastructure and blade information, and error
reporting. See Figure 1-5.
Table 1-1. Control Panel Features
Feature Indicator Description
System power
button
N/A Turns the system on and off. Press to turn on the
system. Press and hold 10 seconds to turn off the
system.
NOTE: The system power button controls power to all
of the blades and I/O modules in the enclosure.
System power
indicator
Off Enclosure does not have power.
Green System power is on.
Amber Enclosure is plugged in but enclosure power is not
turned on.
NOTE: An amber power LED does not indicate an
enclosure error.
USB ports for
keyboard and
mouse
N/A Functional if an optional iKVM module is installed
and front panel ports are enabled (default setting) in
the CMC interface.
NOTE: These ports do not support USB storage
devices. Only connect USB storage devices to the USB
ports on the front panel of the blade.
Video connector N/A Functional if an optional iKVM module is installed
and front panel ports are enabled (default setting) in
the CMC interface.
